AGI Batco 1335 TD Main Assembly Parts Finder
Buy your AGI Batco parts online with direct factory to farm shipping!
Not finding the part you're looking for? Check out the Batco parts finder page at AGI-BATCO (ricambio.net) and contact us with a part number for availability.
Item No. Part No. Description
1 13000304P COLLAPSABLE HOPPER KIT 1300
2 13010008 SUSPENSION BRACKET-NO TABS
3 13020044 PBT HOPPER 20' W/ BRKTS
4 13020049 SPOUT SECTION 10' W/ RTRN MOUNTS
5 13030042-BK 13/15 TRACK SLIDER BLACK
6 13030010 HITCH 30-50
7 13030024 1335-40-45 TD UPRIGHT ARMS
8 13030100 AXLE 30-45-2-1/2" (WITH 8 LUGS)
9 13032094-BK 35/45 SMALL CABLE ATTACH BK
10 13042201 1300 5' WEATHER GUARD STD-61-1/2"
11 13042202 1300 5' WEATHER GUARD FLR- 61-1/2"
12 13042204 WEATHER GUARD 3' STD - 37-1/2"
13 13070007 SPOUT DRIVE ROLLER URE
14 P0113001 CRG BOLT, 1/2X2 ZN
15 P0113013 CRG BOLT, 7/16X1 GR5 ZN
16 P0113020 CRG BOLT, 5/16X1-1/2 ZN
17 P0118004 HEX BOLT, 1X3 GR8 ZN
18 P0115111 HEX BOLT, 3/4X2 GR8 ZN
19 P0118046 HEX BOLT, 3/8X1 GR8 ZN
20 P0115303 HEXSOC FLTHD CSCR, 3/8X1-1/4 UNC ZN
21 P0118013 HEX BOLT, 1/2X1-1/2 GR8 ZN
22 P0118017 HEX BOLT, 1/2X2-1/2 GR8 ZN
23 P0118076 HEX BOLT, 7/16X1 GR8 ZN
24 P0118077 HEX BOLT, 7/16X1-1/2 GR8 ZN
25 P0131017 HEX NUT, 5/16 GR8 ZN
26 P0134026 NYLON LOCK NUT, 3/8 GR8
27 P0134007 NYLON LOCK NUT, 7/16 GR8
28 P0134008 NYLON LOCK NUT, 1/2 GR8
29 P01340101 NYLON LOCK NUT, 5/8 GR8
30 P0134029 NYLON LOCK NUT, 3/4 GR8
31 P0134030 NYLON LOCK NUT, 1 GR8
32 P0141002 SELF DRILLING SCREW 1/4X1
33 P0151006 FLAT WASHER, 1/4 USS STL ZN
34 P0151006 FLAT WASHER, 1/4 USS STL ZN
35 P0151009 FLAT WASHER, 3/8 USS STL ZN
36 P0151026 FLAT WASHER, 3/4 SAE STL ZN
37 P0152010 LOCK WASHER, 5/16 ZN
38 P0161001 COTTER PIN, 1/4X2 ZN
39 P0161002 COTTER PIN, 5/32X1-1/2 ZN
40 P0162001 HITCH PIN, 1/2X3 W HAIRPIN COTTER
41 P0183003 U-BOLT RND, 2-1/2X2-1/2X5/8 ZN
42 P0614301 TIRE ASM-4BOLT ST205/75D15 LRC(KAN)
43 P0712105 CABLE CLAMP-5/16" GALV.
44 P0714102 WINCH-1500# BRAKE
45 P1010001 UNI-MOUNT PLATE CAST
46 P1210030 BELT GUIDE BLOCK
47 P1211301 HOOD-SMALL ROUND 13 SERIES
48 P1211305 ROLLER 2" NYLON
49 P1711002 FLANGE UNIT-1-1/4"-SAFL206-20
50 13032125 OBS BOLT ON ANGLE
51 13030001 STRAIGHT TONGUE
52 13030102 AXLE ARM 30/35TD/45-2-1/2"
53 13031020 13/15 4 BAND TRACK
54 P2513202P 2" U-CLAMP -PAINTED
55 130100811 1300 WG MOUNT BAR KIT WITH ROLLER
56 P11130288 FITTED WP CROSS BAR (NO ROLLER)
57 P1243001 CABLE (ZIP) TIE 14" 120 LB
58 P2227989 OBS - MANUAL HOLDER AND LID
60 P0711107 CABLE-5/16" (40' ) (19884)
61 P2513212P 2" LOCKING U-CLAMP PAINTED
62 P0145002 SQH SSCR, 7/16X2-1/2 UNC CUP BLK
63 13570350 BELT-13"-35TD-68'8" OAL
