Agnew Self Adjusting Spreader

Agnew Steel

SKU:
AG50SA-AG
Sale
$1,500.00
$1,500.00
$1,400.00
You save $100.00
Shipping:
Calculated at Checkout
$1,500.00
$1,500.00
$1,400.00
You save $100.00

Description

Effortless Grain Spreading & Optimized Bin Filling

Maximize the efficiency and quality of your grain storage with the innovative Agnew Self Adjusting Grain Spreader. Designed and patented by Agnew Steel Inc., this spreader automatically adapts to varying grain flow rates, ensuring even distribution without manual adjustments or the need for precise centering of the grain stream. Ideal for farmers and storage operators looking to streamline the bin filling process and maintain grain condition.

Key Benefits:
  • Automatic Adjustment: Eliminates the need for manual adjustments, seamlessly handling fluctuating grain flows from 200 to 15,000 bushels per hour (depending on the model).
  • Even Grain Distribution: Promotes uniform airflow during aeration and drying by preventing grain coning, helping to maintain grain quality and reduce spoilage.
  • Simplified Operation: No requirement to perfectly center the incoming grain flow, saving time and effort during critical filling periods.
  • Versatile Application: Suitable for a wide range of bin diameters (24' to 48') and compatible with standard grains (rated for 50-60 lbs/bushel).
  • Durable Construction: Built by Agnew Steel, known for robust agricultural equipment made in the USA.
Key Features:
  • Patented Self-Adjusting Design: Utilizes a unique, patented mechanism (U.S. Patents incl. 11,697,561, 10,889,455, 11,279,572, 11,511,953) that responds dynamically to grain flow.
  • Simple Installation: Designed to hang directly from the bin fill opening.
  • Two Capacity Models: Available in two models (AG50SA and AG150SA) to match different flow rate requirements.
  • Adjustable Performance: Features adjustable spring settings (accessible via upper/lower holes) to optimize performance based on expected grain flow rates (AG50SA: up to 1500 bu/hr or 1500-5000 bu/hr; AG150SA: up to 7500 bu/hr or 7500-15000 bu/hr).
  • Low Flow Compatibility (AG50SA): The AG50SA model is particularly well-suited for lower flow rates typical of auger filling or dryer bin setups.
  • High Capacity Performance (AG150SA): The AG150SA model handles high-capacity flows up to 15,000 bushels per hour.
Compatibility:
  • Bin Diameter: Suitable for bins ranging from 24 feet to 48 feet in diameter.
  • Grain Type: Designed for standard grains weighing 50-60 pounds per bushel.
  • Fill Method: Compatible with various fill methods including augers and direct flow from dryers.
Why Choose Agnew Steel?
Agnew Steel Inc. is a trusted manufacturer specializing in grain handling and storage solutions. With a focus on innovation and durability, Agnew Steel products, including this patented self-adjusting spreader, are designed to meet the demanding needs of modern agriculture. Choosing Agnew means investing in reliable, American-made equipment built for performance and longevity.

Installation:
The Agnew Self Adjusting Spreader is designed for straightforward assembly and installation. It should be assembled on the ground before lifting into the bin. Basic tools (like 1/2" wrenches) are required for assembly.
  1. Lift the assembled spreader to the bin opening (using a rope is recommended).
  2. Place the hooks over the rim of the bin opening, ensuring the spreader hangs level.
  3. Set the angle of the grain chutes by pressing the plunger and pinning it. Adjust the chutes to deliver grain approximately halfway between the bin wall and the center.
  4. Always maintain at least a 6-inch space between the grain delivery mechanism (e.g., auger outlet) and the top of the spreader to prevent grain backup.
Detailed instructions, including diagrams for assembly, are available in the manufacturer's assembly and installation manual.


Product Specifications:
  • Product Type: Gravity Grain Spreader
  • Brand: Agnew Steel Inc.
  • Models: AG50SA, AG150SA
  • Function: Self-adjusting grain distribution
  • Compatible Bin Diameters: 24 ft to 48 ft
  • Compatible Grain Weight: 50-60 lbs/bushel
  • Flow Rate (AG50SA): 200 - 5,000 bushels per hour
  • Flow Rate (AG150SA): 400 - 15,000 bushels per hour
  • Material: Steel
  • Installation: Hangs from bin fill opening
  • Origin: Made in USA
  • Weight: Approx. 65 LBS
  • Patents: U.S. Patent Nos. 11,697,561; 10,889,455; 11,279,572; 11,511,953
  • Assembly Required: Yes (Basic tools: 2 x 1/2" wrenches)
Configuration Options: Choosing Your Model

The Agnew Self Adjusting Spreader is available in two models, differing primarily in their grain flow capacity. Please select the model from the dropdown menu that best matches your operational needs:
  • AG50SA (SKU: AG50SA-AG):
    • Flow Rate: Handles 200 to 5,000 bushels per hour.
    • Ideal Use Cases: Best suited for standard auger filling systems or operations involving grain dryers where fill rates are typically lower.
    • Bin Diameter: 24' to 48' (See compatibility note).
    • Performance Setting: Spring adjustable for <1500 bu/hr or 1500-5000 bu/hr.
  • AG150SA (SKU: AG150SA-AG):
    • Flow Rate: Handles high flow rates from 400 to 15,000 bushels per hour.
    • Ideal Use Cases: Designed for larger operations, faster fill systems, or higher capacity grain handling equipment.
    • Bin Diameter: 24' to 48'.
    • Performance Setting: Spring adjustable for <7500 bu/hr or 7500-15000 bu/hr.
Important Considerations:
  • Verify Flow Rate: Carefully consider your maximum grain flow rate to ensure you select the appropriate model (AG50SA or AG150SA).
  • Shipping: Standard ship time is 1-2 weeks (as per original listing; confirm current lead times if critical).

Videos

Extra Information

Brand:
Agnew Steel
Weight:
65.00 LBS
