Save even more on mill-duty grain handling parts and accessories at Grain Handling Direct.
This listing is OEM Nolin Milling equipment sold and supported by Grain Handling Direct. Configure size, gauge, lining, and finish on this page and check out here — no need to go elsewhere to order.
These fittings are mill-duty steel fabrications for dry bulk material handling: spouting, valves, slide gates, adjustable spout ends, and industrial ductwork for air and dust systems. Construction uses laser cutting, high-definition plasma, computerized rolling, automatic seam welding, press brakes, and stamping so parts match the spout and gate patterns used throughout the grain industry.
Technical Specifications
Sizes are outside-diameter (round) or outside width (square) unless noted. Select diameter/size, gauge, lining, and finish on this page; price, weight, and freight cube update with the option set.
Dust-control load-out sock. Flexible discharge sock that contains dust at truck/rail load-out. Replacement socks are sold separately from the hoop/frame. Size to the load-out spout OD. A complete 12" assembly typically ships in a 24" × 16" × 16" carton.
Construction. Laser-cut and plasma-cut carbon, galvanized, or 304 stainless from 14 ga through 1/4" plate. Seams welded; flanges punched to the standard patterns used on this product family. Custom hole layouts are available. Typical capacity guidelines use ~70 BPH per square inch of interior area for 8" and larger spouts on clean corn, soybeans, or wheat at 40° or greater. Target grain velocity under 1,750 FPM to limit kernel damage and premature wear .
Available option families include diameter/size (commonly 4"–24", some gates to 36"), gauge (14, 12, 10, 7 ga, 1/4" wall), lining (none, 7 ga AR, 1/4" AR, blue urethane, orange urethane, ceramic-chip urethane, ceramic tile), and finish (primed gray, galvanized, stainless).
Capacities assume clean, dry whole grain at 40° or steeper. Wet corn should be spouted at 45° minimum. Lining and fittings reduce capacity. Use these figures as planning guidelines and confirm the selection for your application before you order.
